商品名称：红外线测温仪AZ3580   红外线测温仪AZ3580

红外线测温仪AZ3580产品简介：
THE MODEL 3580 IS A HIGH ACCURACY INFRARED TEMPERATURE TRANSDUCER THAT IS COMPLETELY SELF-CONTAINED. DIGITAL OUTPUT PROVIDES EASY INTERFACE WITH ANY UP/UC.
红外线测温仪AZ3580的参数：
CONNECTOR CONFIGURATION :
Pin No.
Terminal Name
I/O
 Description
1
Trigger
I
 LEnable (0) and Disable (1),3 v. Controlled by open collector transistor.
2
Gnd
Ground
3
Vcc
I
 6V-15V
4
Digital output
O
RS-232Like(3 level)

DIGITAL OUTPUT FORMAT:
Format: RS-232Like, 2400 bps, 8 data bits, no parity, 1 stop bit.
Protocol: ASCII code; Txxx.xC:Txx.xK[CRLF]. Where:
The 1st xxx.x is a floating temperature value (unit ℃) from 50.0
to 500.0, The 2nd xx.x is a floating value of calibrated environment
temperature (unit degreeK) used for changing emission rate.

ITEM Specification
Supply voltage (Vcc) DC 6V ~ 15V
Temperature Range -40 ~ 500℃ ( -40~932 oF)
Temperature Accuracy ±2% or ±2℃ (Temperature >= 0℃) ±5℃ (Temperature < 0℃)Whichever is greater
Resolution 0.1℃ or 1.0℃ ( >100℃)
Output signal RS-232 (3V level)
Emission rate 0.95
Response time 0.2 second
Distance: Spot 8:1
Laser indicator Optional
Operating Environment 0 ~ 65℃ 5% ~ 95%RH
Connector 4pins with 2.0mm pitch
Customer design PCB
Application:
Automative: HVAC Climate control.
Industrial: Microwave oven,Oven,OA,
Non-contact Thermometer
